Question

Please reply my question regarding L9369 GIO

  • April 15, 2024
  • 0 replies
  • 402 views


I am writing because I have a question about the L9369 chip.

The second case of above table ( SPI_GIOx_HSCtrl == 0 and SPI_Off_Giox == 1) , Output  is set to HIGH.

I'm curious why GIOx Output is HIGH when SPI_GIOx_HSCtrl is 0.

Thank you.

This topic has been closed for replies.
