TouchGFX performance issues

[seg_fault01]



Hello,

I use the STM32H747 running at 400 MHz (M7) together with a display that has a resolution of 800x480 pixels.
I have set up a project in TouchGFX Designer based on the Gauge example project.
The design includes 2 gauges. The chrome ART is enabled according to the CubeMX configuration.
How can I for sure say, that the DMA2D features are used? The only thing that happens
in the project is that the gauge needles move based on the values of an array (the values change in each frame).
The system should run at around 60 FPS, but only manages 30 Fps and therefore drops every 2nd frame (MCU is at 90% utilization).
The needle images are 3x150 pixels (I'm using RGB888) and are stored in internal flash.
What changes can I make to improve the performance of the two gauges?



[seg_fault01]

In an attempt to improve performance, I've followed this guide: Changing the Pixel Format of an Application | TouchGFX Documentation to change the pixel format from RGB888 to RGB565. I've also called:

 OTM8009A_Init(&OTM8009AObj ,OTM8009A_FORMAT_RGB565, OTM8009A_ORIENTATION_LANDSCAPE);

instead of:

 OTM8009A_Init(&OTM8009AObj ,OTM8009A_FORMAT_RGB888, OTM8009A_ORIENTATION_LANDSCAPE);

The changes resulted in this beeing display:

Any guidance on how to change the pixel format?



My experience is similar to what is described in this thread: STM32H747I-DISCO 16-bit Color Depth Problem - STMicroelectronics Community

[Mohammad MORADI ESFAHANIASL]

Hello @seg_fault01 ,

To ensure the functionality of ChromART, you can simply use this function to enable or disable it and check the effect on the performance:

HAL::getInstance()->enableDMAAcceleration(value); //value = true/false

You can see the same scenario in the Dice Animation demo or the Screen Transitions.

As for the performance of gauges, I don't have much to say since they are computationally expensive. However, if possible, placing them on two separate screens or decreasing their size will help with the issue (which are very obvious solutions :grinning_face_with_sweat:)

Also, I can confirm that changing the pixel format results in an invalid framebuffer. I will spend some time on it and get back to you with a conclusion.

Best regards,

[seg_fault01]

Hello Mohammad,

I really appreciate your answer. Activating or deactivating the DMA2D features does not improve performance. It is not possible to split the gauges into 2 screens and unfortunately they will be even larger in the final design....

I hope a change in the pixel format goes hand in hand with a slight improvement in performance, as there is less data to process.

[seg_fault01]

Still interested
