Writing Option Bytes using HEX file is failed on STM32C0, but successful on STM32L0

[FArdi.1]

I need to write option bytes using HEX file, but so far can't work on STM32C0. It was working well in STM32L0.

Any solution?

Updating the option bytes using "-ob [OptByte=<value>]" is working, but I prefer using the HEX file.



STM32C031

STM32CubeProgrammer v2.15.0

stm32_programmer_cli -c port=SWD freq=8000 mode=UR -e all -d "OptBytes_C0.hex"

The program shows "File download complete"

Before: 0x1FFF7800 : FFFFFEAA 00000155

After: 0x1FFF7800 : FFFFFEAA 00000155 <<< Option bytes unchanged





STM32L031

STM32CubeProgrammer v2.15.0

stm32_programmer_cli -c port=SWD freq=8000 mode=UR -e all -d "OptBytes_L0.hex"

The program shows "File download complete"

Before: 0x1FF80000 = FF5500AA

After: 0x1FF80000 = FFFF0000 <<< Option bytes changed as expected





[Simon.T]

Hello @FArdi.1 ,



I confirmed the issue and I have submitted an internal ticket addressing your request to the dev team.

Internal ticket number: 170523 (This is an internal tracking number and is not accessible or usable by customers).



Best regards,



Simon

[Billy OWEN]

Hi @FArdi.1



The forum moderator had marked your post as needing a little more investigation and direct support. An online support case has been created on your behalf, please stand by for just a moment and you will hear from us.



Regards,

Billy

[FArdi.1]

Thanks. I saw the newly open case in online support page. I will be there to follow up this case.

[FArdi.1]

Update:

No solution, and there is no plan to support this feature.



Quoted from online support case:

"the operation of programming option bytes for STM32C0 via SWD interface is not supported currently."
